| Series |
W Series |
| Model |
AP124W |
AP224W |
AP324W |
| Capacity |
120 g |
220 g |
320 g |
| Minimum Display |
0.1 mg |
| Calibration Weight |
Built-in |
| External Calibration Weight Range for Span Calibration |
45 to 120.009 g
(100 g) |
95 to 220.009 g
(200 g) |
95 to 320.009 g
(300 g) |
| Repeatability (Standard deviation) |
0.1 mg |
0.15 mg |
| Minimum Weight *1 |
200 mg |
| Linearity |
±0.2 mg |
±0.3 mg |
| Response Time *2 |
Approx. 2 sec. |
| Operating Temperature/Humidity Range |
5 to 40°C 20 to 85% *3 |
| Sensitivity Stability Against Temperature Range |
±2 ppm/°C (10 to 30°C) |
| Pan Size |
Φ91 mm |
| Body Dimensions |
Approx. 212 (W) x 367 (D) x 345 (H) mm |
| Weight |
Approx. 7.0 kg |
| Display |
OEL display (dot matrix) |
| Input/Output Terminal |
RS-232C (D-sub9P plug) USB host (Type A) USB device(Type B) Ionizer |
|
